The Canon EOS C400 Full Frame RF Cinema Camera. RF lenses enable richly expressive, high quality imaging. The high speed communication capabilities of the RF mount makes operation intuitive and stress free. Co ordinated control of camera and lens IS via RF mount communication achieves powerful image stabilisation.
The 6K full frame back illuminated stacked CMOS sensor and DIGIC DV7 processor deliver breathtakingly beautiful visuals with support for enhanced 4K image quality with 6K oversampling and wide 16 stop tonality. Full frame readout is supported along with Super 35mm and Super 16mm modes.
EOS C400's combination of high image quality, movie performance, compact size and full range of interfaces for greater operability makes it ideal for shooting in a range of environments from filmmaking to live events
Dual Pixel CMOS AF II offers advanced high speed, high precision AF. Algorithms which utilise deep learning enable high performance subject detection which provides high speed AF that captures the subject instantly.
Users can fully utilise their existing EF lenses by attaching an EF EOS R adapter. PL lenses can also be attached using a new PL RF mount adapter.
The Canon EOS C400 Full Frame RF Cinema Camera. RF lenses enable richly expressive, high quality imaging. The high speed communication capabilities of the RF mount makes operation intuitive and stress free. Co ordinated control of camera and lens IS via RF mount communication achieves powerful image stabilisation.
The 6K full frame back illuminated stacked CMOS sensor and DIGIC DV7 processor deliver breathtakingly beautiful visuals with support for enhanced 4K image quality with 6K oversampling and wide 16 stop tonality. Full frame readout is supported along with Super 35mm and Super 16mm modes.
EOS C400's combination of high image quality, movie performance, compact size and full range of interfaces for greater operability makes it ideal for shooting in a range of environments from filmmaking to live events
Dual Pixel CMOS AF II offers advanced high speed, high precision AF. Algorithms which utilise deep learning enable high performance subject detection which provides high speed AF that captures the subject instantly.
Users can fully utilise their existing EF lenses by attaching an EF EOS R adapter. PL lenses can also be attached using a new PL RF mount adapter.
Lens mount | RF mount |
---|---|
Sensor | 35mm full frame CMOS sensor |
Number of pixels | Total pixels: approx. 26.7 megapixels Effective pixels: up to approx. 19 megapixels |
ISO sensitivity | 160 - 25600 (Extended: 100 - 102400) |
BASE ISO | 800 / 3200 / 12800 Auto change (Ex.: Canon Log 2, Canon Log 3, RAW recording) |
Sensor mode | Full frame, Super 35mm Crop, Super 16mm Crop |
ND filter | Mechanical ND filter (2 / 4 / 6 / 8* / 10 stops*) *With extender |
Gamma | Canon Log 2, Canon Log 3, Canon 709, BT.709 Wide DR, BT.709 Standard, PQ, HLG |
Frame rate |
|
Gamma | Canon Log 2, Canon Log 3, Canon 709, BT.709 Wide DR, BT.709 Standard, PQ, HLG |
Frame rate | 6K 59.94P/50.00P (RAW) 4.3K 59.94P/50.00P(RAW) 4K 59.94P/50.00P (RAW/XF AVC/XF HEVC S/XF AVC S) 2K 59.94P/50.00P (RAW/XF AVC/XF HEVC S/XF AVC S) |
Color space | Cinema Gamut, BT.2020 Gamut, BT.709 Gamut |
White balance | Auto, sunlight, tungsten, color temperature (2000K to 15000K), settings A/B |
Dynamic range | 16 stops |
AF | Dual Pixel CMOS AF II |
Recording Format | Movies: Cinema RAW Light, XF AVC, XF HEVC S, XF AVC S Photos: JPEG |
Maximum frame rate* (slow & fast, etc.) | Full frame 6000x3164/60P Super35mm Crop 4368x2304/100P, 4096x2160/120P Super16mm Crop 2184x1152/180P |
Recording format (audio) | Linear PCM 24 bit/48kHz/4ch AAC 16 bit/48kHz/2ch (XF HEVC S / XF AVC S) |
Recording media | CFexpress card SD card |
LCD monitor | 3.5 inch LCD 2.76 million dots, touch panel |
Viewfinder | No |
Multi-function shoe (21 pin) | Yes (with power contacts) |
Wi-Fi | Internal |
Lens | Yes |
SDI OUT | Yes (BNC terminal x1, 12G/6G/3G/HD SDI) |
MON. | Yes (BNC terminal x1, 3G/HD SDI) |
HDMI | Type A |
INPUT | Mini XLR x2 (AES/EBU not supported) |
Ethernet | Yes |
USB | USB Type C, for smartphone connection |
VIDEO | USB Type C *1 , for LCD connection |
GRIP | USB Type C 1 , for grip connection |
MIC | Φ3.5mm stereo mini jack |
Headphone | Yes (stereo) |
REMOTE A (φ2.5 mm) | Yes |
REMOTE B (RS 422) | No |
TC (TIME CODE) | Yes (DIN terminal) |
G LOCK | Yes (DIN terminal) |
SYNC | Yes (DIN 2) |
RET | Yes (DIN 2) |
DC IN | 12V XLR (4 pin) |
Power / Other | Battery: BP A30N, BP A60N |
Operating temperature | Guaranteed performance conditions: Approx. 0 to 40°C, 85% (relative humidity) Guaranteed operating conditions: Approx. 5 to 45°C, 60% (relative humidity) |
Dimensions (W x H x D) | Approx. 142 x 135 x 135mm |
Main body weight | Approx. 1540g |
